Cable Core Bare Tinned Copper Wire 0.05-1.70mm Winding Twisting Drawing Bunching Bunchers Stranding Extruder Machine
-
Electric
-
New
-
Ce, ISO
-
12 Months
-
Automatic
-
2
High Speed double twist Bunching Machine
he twins bunching machine has been developed to produce very accurate strands with very small sections for the electronic wire and automobile wire industry. It can produce simultaneously two different strand sections, on equal or different reels, at the same rotation speed. Two rotate shafts drive by one motor ,thus achieve the environmental goal and low power. With the main shaft meter counter, the machine twist the same types of line, and the tolerance is only 0.1‰ .PLC control the main spindle lubrication equipment, add the grease regularly, avoid inlet the excess or lack grease, reduce the stopped time ,low the maintenance charge.
Equipment model FC-250B FC-300B FC-400B FC-450B Twisting usage Apply for the bunching of aerospace,medical instrument,cellphone,notebook
And ultra fine conductor(above seven pcs of alloy wires,tinned wires,silver jacketed wires and enamelled wires)Single wire dia(mm) 0.03-0.18 0.04-0.28 0.05-0.32 0.05-0.32 Stranding section area(mm2) 0.0049-0.3 0.0088-0.45 0.0137-1.0 0.0137-1.0 Pitch(mm) 0.8-10.8 1.6-21.6 3.1-33.3 3.1-33.3 Direction of lay:optional for right or left Take up bobbin 200-250 250-300 300-400 300-450 Max rotating speed 4000rpm(8000TPM) 3500rpm(7000TPM) 3000(6000TPM) Main motor power:3.7KW Inverter power:3.7KW Tension control:PLC+touchscreen +magnetic powder clutch,ensure the constant tension from empty to full bobbin Magnetic powder clutch 0.3kgf 0.6kgf Protection:automatically brake/stop 1)wire inside and outside is broken 2)the preset length is arrived Brake mode Electromagnetic brake Traversing method:rolling wire with ring drive units,winding pitch and width are adjustable
