Availability: | |
---|---|
Electric
New
ISO, CE
24 Months
Automatic
>1,000,000 Shots
Equipment model | FC-1000B | FC-1250B | FC-1600B | ||
Twisting usage | Apply for the twisting of above seven pcs of bare copper wires,tinned wires,alloy aluminium wires etc.BVR and RVV),double twisting for core wires. | ||||
Single wire diaφ(mm) | 0.3-2.14 | 0.5-2.52 | 0.5-2.52 | ||
Stranding section area | 6.0-25 | 10-35 | 10.0-50 | ||
Core wire single wire diaφ(mm) | 2.0-4.0 | 3.0-6.0 | 3.0-6.0 | ||
Core wire stranding outer dia(mm) | 4.0-10.0 | 6.0-12.0 | 6.0-15.0 | ||
Pitch(mm) | 35-149 | 41-155 | 60-260 | ||
Direction of lay | Optional for right or left | ||||
Take up bobbin(mm) | Dia1000 | Dia1250 | Dia1600 | ||
Max rotating speed | 1000rpm(2000TPM) | 800rpm(1600TPM) | 600rpm(1200TPM) | ||
Main motor power | 18.5kw | 22kw | 30kw | ||
Inverter power | 18.5kw | 22kw | 30kw | ||
Tension control method | Magnetic powder clutch+PLC+touchscreen,ensure the constant tension from empty to full bobbin | ||||
Magnetic powder clutch | 20kgf | 20kgf | 40kgf | ||
Protection | 1.wire inside and outside is broken,automatically brake/stop 2.The preset length is arrived | ||||
Brake mode | Electromagnetic brake | ||||
Traversing method | Rolling wire with ring drive units,winding pitch and breadth are adjustable | ||||
Operation mode | Touchscreen operation | ||||
Dimension(mm) | 4000L*2200W*2100H | 4500L*2600W*2500H | 5000L*3000W*3000H |
