Availability: | |
---|---|
Computer Control
Copper Wire Electrical Wire
According Customer′s Requirement
4500L*2600W*2500H(mm)
FC
China
Equipment models | FC-1000B | FC-1250B | FC-1600B |
Twisting usage | Apply for twisting of seven pcs or above, such as 1) bare copper wires, 2) tinned wires, 3)silver jacketed wires ,4)enameled wires, 5)double twisting for core wires. | ||
Single wire dia(mm) | 0.30-1.7 | 0.5-2.14 | 0.5-2.52 |
Stranding section area (mm²) | 6.0~25.0 | 6.0~35.0 | 16.0~95.0 |
Core wire single wire dia(mm) | 2.0~5.0 | 3.0~6.0 | 3.0-10 |
Core wire stranding outer dia(mm) | 4.0~10.0 | 6.0~15.0 | 8.0~20.0 |
Pitch(mm) | 35-200(12 classes) | 50-250(12 classes) | 80-350(12 classes) |
Direction of lay | Free for right or left | ||
Take up bobbin Outer dia*bore*outer width | 1000*80*750 | 1250*80*950 | 1600*80*1180 |
Max rotating speed | 1000rpm(2000twist) | 800rpm(1600twist) | 600rpm(1200twist) |
Main motor power | 18.5KW | 22KW | 30KW |
Inverter power | 18.5KW | 22KW | 30KW |
Tension control | Touch screen+ PLC+ magnetic powder clutch, ensure the constant tension from empty to full bobbin | ||
Magnetic powder clutch | 20kgf | 20kgf | 40kgf |
Protection | automatically brake/stop 1)wire inside and outside is broken 2)the preset length is arrived | ||
Brake mode | Electromagnetic brake | ||
Traversing method | Rolling wire with ring drive units, winding pitch and breadth are adjustable | ||
Operation mode | Touch screen operation | ||
Dimension L*W*H(mm) | 4000*2200*2100 | 4500*2600*2500 | 5000*3000*3000 |
