0.04-2.52mm Electrical Copper Steel Wire Winding Plastic PVC Extrusion Bunching Buncher Stranding Machine

Availability:
facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
whatsapp sharing button
sharethis sharing button
  • Electric

  • New

  • ISO, CE

  • 12 Months

  • Automatic

  • 300,000-1,000,000 Shots

Merits:It is the latest developed machine.This machine replace the model 200tube bunching machine with the high productivity.It is mainly produce 19pcs of wire twist at one time,and its capacity is 4.5times of the 200 tube bunching machine,low power,small floor place,low noise and other merits.

0.04-2.52mm Electrical Copper Steel Wire Winding Plastic PVC Extrusion Bunching Buncher Stranding Machine
0.04-2.52mm Electrical Copper Steel Wire Winding Plastic PVC Extrusion Bunching Buncher Stranding Machine
0.04-2.52mm Electrical Copper Steel Wire Winding Plastic PVC Extrusion Bunching Buncher Stranding Machine
0.04-2.52mm Electrical Copper Steel Wire Winding Plastic PVC Extrusion Bunching Buncher Stranding Machine



0.04-2.52mm Electrical Copper Steel Wire Winding Plastic PVC Extrusion Bunching Buncher Stranding Machine 0.04-2.52mm Electrical Copper Steel Wire Winding Plastic PVC Extrusion Bunching Buncher Stranding Machine
equipment model 1+6(630F)+12 1+6(800F)+12
equipment composition 650B buncher+630F twisting machine+630multiple drawing bobbins active pay off machine 800B buncher+800F twisting machine+800multiple drawing bobbins active pay off machine.
twisting usage It is applicable to bunching 19pcs BVR copper wire in one time.
single wire diameter(mm) Φ0.16~Φ0.64
stranding section area(mm²) 0.38~6.0
pitch 11.6-100(34pcs pitch) 23-160(22 pcs pitch)
direction of lay optional for right or left
pay off bobbin Φ630*Φ127*475 Φ800*Φ127*600
pay off type active pay off/magnetic pay off
take up bobbin Φ630*Φ127*475 Φ800*Φ127*600
1+6 max speed 2000(4000twist) 1500(3000twist)
main machine max rotating speed 2000(4000twist) 1200(2400twist)
total power 21KW 35KW
take up tension control method touch screen+PLC+magnetic powder clutch,it may ensure the constant tension from empty bobbin to full bobbin
take up magnetic clutch 5kgf 10kgf
protection machine will automatically brake when wire inside and outside is broken,machine will automatically stop when the preset length is arrived.
brake mode electromagnetic brake
traverse type rolling ring drive units,windling pitch and breadth are adjustable
operation mode touch screen operation
